• 10 incubators and three timers
• 7-inch Color LCD, Touch screen
• Flow cell and Cuvette test mode compatible
• Real-time curve showing
• 7 wavelength, 90 test item pre-programmed Memory for 10,000 sample results
• Light source hibernate function making lamp life longer RS232 interface, PC connecting

Specifications

• Test mode: Kinetic, End point, Two point, Absorbance
• Wavelength: 7 standard filters, 340, 405, 492, 510, 546, 578, 630 nm, 1 free position
• Wavelength precision: ±2 nm, width ≤ 10nm
• Absorbance range: 0~4.500 Abs
• Absorbance precision: outside 0.0001 Abs , inside 0.00001 Abs
• carry over: < 1%
• Repeatability CV: < 1%
• Incubator: 37℃、30℃、25℃、Precision : ±0.1℃
• Sample volume: 0~3000 uL (≥500uL recommend)
• Data Storage: ≥10000
• Quality control curve: 、SD、CV%、L-J quality control curve for every test item
• Flow cell: 32 uL quartz glass, 10 mm
• Lamp: Philips 6V 10W Halogen Lamp with long life
• Screen: 7 inch color LCD
• CPU: ARM series high speed micro CPU
• Printer: Internal thermal sensitive printer
• Interface: RS-232
• Work Environment: Temperature 0℃ ~ 40℃, Humidity: ≤80%
• Power supply: 100~240VAC，50-60Hz，100VA
• Dimension: 340(L)*270(W)*160(H)
• Weight: 5 kg

Usual test list

• Liver function: ALT AST ALP TBIL TP ALB TTT CHE Nh
• Renal function: BUN CRE UA URE CO2CP YGT
• Lipids: TCHO TG HDLC LDLC
• Cardiac function: CK CKMB LDH
• Immune proteins: IGA IGG IGM C3
• Others: GLU HGB AMS
