Vi-2600HD
Full Integrated Endoscope Imaging System
Integrated 4-in-1 endoscope video imaging systems
Integrated Medical display, EndoCamera, Cold Light Source and WorkStation
|
FULL HD CAMERA |
|
|
Sensor |
1/2" CMOS Full HD |
|
Resolution |
1920 * 1080P, 60fps |
|
Scanning |
progressive |
|
Min.Illuminance |
O.OlLux |
|
Shutter |
Auto |
|
W/B |
Auto/Manual |
|
RGB/SPOT |
Auto |
|
VIDEO OUTPUT |
|
|
Output Mode |
HDMI, Synchronize Positive |
|
GROSS SIZE & WEIGHT |
|
|
VI-1200HD |
L700 * W308 * HS13mm/l1kg |
|
VI-22D0HD |
L700 * W308 * H513mm/15kg |
|
VI-2600HD |
L844 * W335 * H597mm/19kg |
|
MONITOR |
|
|
Aspect Ratio |
16:9 |
|
Size |
12"/22"/26" |
|
LED LIGHT SOURCE |
|
|
Power |
60W |
|
Illuminance |
≥700 000lux |
|
Color Temp. |
5000-6000K |
|
CRI |
≥90 |
|
Life Cycle |
≥30 000 hours |
|
HD-DVR |
|
|
Resolution |
H 264 1920 * 1080 |
|
Video/Photo Format |
mp4/jpeg |
|
Functions |
Freeze/Replay/Snapshot/Record |
|
Storage Media |
Flash/SD |
